B&K Precision Corporation

22820 Savi Ranch Parkway, Yorba Linda, CA 92887

Tel: 714-921-9095, Fax: 714-921-6422

www.bkprecision.com

Specifications subject to change without notice

Data Sheet

Model 325

True RMS AC/DC Power Clamp

Meter

The lightweight, portable, battery-powered Clamp-On meter measures the most

common AC Volts, DC Volts, and AC current needed to troubleshoot residential

and small commercial electrical systems.

■ Back light 33/4 digits LCD with max. reading 3999, plus decimal point, unit

symbol indication

■ Auto range,Auto power off,Auto zero

■ High speed bargraph

■ Function keys: Max./Min. Hold, Data Hold,Trms Positive and Negative Peak Hold

■ Test Ranges:ACV,ACA, DCV, DCA, Ω,WATT, Frequency, Continuity

■ Jaw openings 1.37" (35mm)

DC Current

Range 400A, 600A

Resolution 0.1A, 1A

Accuracy 1.5% + 5 dgt

2% + 5 dgt

AC Current (True RMS : From 10% to 100% of Range)

Range 400A, 600A

Resolution 0.1A, 1A

Accuracy

40 - 65Hz 2.0% + 5 dgt

2.0% + 5 dgt

65 - 1kHz 3.0% + 8 dgt

3.0% + 8 dgt

DC Voltage

Range 400V, 600V

Resolution 0.1V, 1V

Accuracy 1.0% + 3 dgt

AC Voltage (True RMS : From 10% to 100% of Range)

Range 400V, 600V

Resolution 0.1V, 1V

Accuracy

40 - 400Hz 1.2% + 5 dgt

400 - 2kHz 2.0% + 5 dgt

AC + DC WATT

Range 40KW, 400KW

Resolution 0.01KW, 0.1KW

Accuracy 5.0% + 5 dgt

Resistance

Range 4000ohm

Resolution 1ohm

Accuracy 1.0% + 3 dgt

Frequency

Range 4kHz, 40kHz, 400kHz

Resolution 1Hz, 10Hz, 100Hz

Accuracy 0.5% + 3 dgt

Specifications

model

325

The Model 325 AC/DC True RMS Power Clamp Meter provides

safe, non-invasive measurements of up to 400KW, 400 Amps AC

(± 2%+10 dgt), and measures up to 600 Volts AC (±1%+10 dgt),

and up to 600 Volts DC (±1.5%+10 dgt) utilizing the a pair of stan-

dard test leads. It provides the ability to measure up to 4000Ω of

resistance (±1%+5 dgt) and 40Ω of audible continuity.

The unit’s Data Hold feature allows the user to freeze the LCD

display reading. Other features include a front panel 3-3/4 digit

LCD display, automatic range selection, over-range and low battery

indicators, automatic power off after 30 minutes, and a maximum

jaw opening of 1.37” inches (35mm).

The Model 325 utilizes a 9V battery (NEDA 1604 IEC 6F22 JIS

006P) with an expected life of approximately 200 hours. Its com-

pact size (1.69(H) x 2.95(L) x 8.58(D)) and lightweight (13.24 oz

including battery) makes the Model 325 ideal for single-handed

operation

Model 325 1
